| 원래 장소: | 중국 |
|---|---|
| 브랜드 이름: | XQ |
| 인증: | CE |
| 모델 번호: | XQHFL-110 |
| 최소 주문 수량: | 1개 세트 |
| 가격: | USD 12000-13000 Per Set |
| 포장 세부 사항: | 우든 패킹 |
| 배달 시간: | 10일이요 |
| 지불 조건: | 전신환 |
| 공급 능력: | 달 당 10개 세트 |
| 보증: | 12개월 | 타입: | 베개 포장기 |
|---|---|---|---|
| 효율: | 40-150은 1분에 불룩해집니다 | 기계류 테스트 리포트: | 제공됩니다 |
| 화면 출하검사: | 제공됩니다 | 용법 :: | 식품 /medicines/화장품 |
| 강조하다: | 40 BPM 수평 유동 랩 기계,40 BPM 유동 랩 곤포기,40 BPM 베개 곤포기 |
||
Automatic 40 BPM Horizontal Flow Wrap Machine For Food Cosmetic
Automatic Horizontal Flow Wrap Machine For Food And Cosmetic Packing
Characteristic
The bag length requires no manual setting. The machine can automatically detect and set the length; The Dual-VFD simple mechanic structure is stable, which requires easy maintenance, and of low-wearing and long-running life; The main control adopts SCM, digital display and controlled by VFD. Friend HMI makes operation direct and easy; Running speed and the length of the bag are controlled by two VFDs, with stepless speed shift and wide adjustment range, which makes matching well with the upstream machines possible; High sensitive photocell eyes system makes tracking accurate; Independent temperature control for each sealing device (mid sealing and end sealing), which is suitable for a wide variety of packing materials. Device for intermission air charging and alcohol spray can be mounted (only for the food industry).
Technical data
| Model | XQHFL-110 |
| Film Width | Max.250mm |
| Bag Length | 65-280mm |
| Bag Width | 30-110mm |
| Product Height | Max.45mm |
| Speed | 40-230 Bag/min |
| Power | 220V 50/60Hz 2.4KW |
| Machine Size | 3920*670*1320 mm |
| Weight | About 500 KG |
